| Nominal diameter of conductor | Insulation thickness | The thickness of the sheath | Cable approximate outer diameter | Test voltage |
| mm2 | mm | mm | mm | KV/min |
| 1×1.5 | 0.8 | 1.4 | 6.1 | 3.5 |
| 1×2.5 | 0.8 | 1.4 | 6.5 | 3.5 |
| 1×4 | 1 | 1.4 | 7.4 | 3.5 |
| 1×6 | 1 | 1.4 | 7.9 | 3.5 |
| 1×10 | 1 | 1.4 | 9.2 | 3.5 |
| 1×16 | 1 | 1.4 | 10.3 | 3.5 |
| 1×25 | 1.2 | 1.4 | 12 | 3.5 |
| 1×35 | 1.2 | 1.4 | 13.2 | 3.5 |
| 1×50 | 1.4 | 1.4 | 14.9 | 3.5 |
| 1×70 | 1.4 | 1.4 | 16.7 | 3.5 |
| 1×95 | 1.6 | 1.5 | 19.3 | 3.5 |
| 1×120 | 1.6 | 1.5 | 20.9 | 3.5 |
| 1×150 | 1.8 | 1.6 | 23.1 | 3.5 |
| 1×185 | 2 | 1.7 | 25.6 | 3.5 |
| 1×240 | 2.2 | 1.8 | 28.8 | 3.5 |
| 1×300 | 2.4 | 1.9 | 31.9 | 3.5 |
| 1×400 | 2.6 | 2 | 35.5 | 3.5 |
| 1×500 | 2.8 | 2.1 | 39.7 | 3.5 |
| 1×630 | 2.8 | 2.2 | 43.7 | 3.5 |
| 1×800 | 2.8 | 2.4 | 46.1 | 3.5 |
